Thermal Oil Heater

Request a Quote

View All: http://asphaltmixsolution.com/6-thermal-oil-heater.html

for Asphalt Mixing Plants

Description

Thermal oil heaters are an ideal choice for asphalt heating. Thermal oil heated inside the heater is moved to the equipment through the use of a circulating pump, then returned to the thermal oil heater from the equipment oil outlet, thus forming a reusage cycle. The oil heater primarily uses oil and gas as the fuel, and is widely used for asphalt storage and asphalt mixing.

As the auxiliary equipment of the asphalt plant, we have produced a number of different thermal oil heaters, and shown below are a few cases we have customized, Please contact us if you're not sure how to choose the right one for your needs, or need customization services.

Model	Rated calorific value 104Kcal/h	Rated pressure MPa	Maximum working temperature ℃	Thermal efficiency %≥	Circulated flow m³/h	Pipe connection caliber DN
180Y(Q)	15	0.6	320	80	40	65
350Y(Q)	30	0.6	320	80	40	65
580Y(Q)	50	0.6	320	80	60	80
820Y(Q)	70	0.6	320	80	100	100
940Y(Q)	80	0.6	320	80	100	100
1200Y(Q)	100	0.7	320	80	100	125
1400Y(Q)	120	0.7	320	80	100	125
1750Y(Q)	150	0.6	320	80	160	150
2400Y(Q)	200	0.6	320	80	160	150
2900Y(Q)	250	0.6	320	80	200	200
3500Y(Q)	300	0.6	320	80	200	200
4000Y(Q)	350	0.6	320	80	260	200
4700Y(Q)	400	0.7	320	80	260	200
5800Y(Q)	500	0.7	320	80	300	200
7000Y(Q)	600	0.8	320	80	340	250

Features

This series of equipment uses a frame structure that is easy to move.
The equipment uses an automatic burner to provide the temperature, and it is easy to operate.
Optional fuels: fuel oil and gas.
