Pipe Grab
Request a Quote
Description:
Pipe grabber is a transformed device that’s modified and upgraded from loader, which is efficiency, of high adaptability and vastly applied, does steel pipe carrying works in tree farms, stations, docks, ports, oil fields, etc.
| Model | LTP150 | LTP180 | LTP200 |
| Overall length | 2300 mm | 2300 mm | 2300 mm |
| Overall width | 1480 mm | 1715 mm | 1680 mm |
| Overall height | 1350 mm | 1454 mm | 1600 mm |
| Max. opening | 1500 mm | 1790 mm | 1973 mm |
| Weight | 1023 kg | 1396 kg | 1800 kg |
| Max. grab weight | 3 T | 5 T | 7 T |
| Maximum hold around | 760 mm | 900 mm | 1000 mm |
| Minimum hold around | 630 mm | 565 mm | 565 mm |
| Pressure range | 16-21 MPa | 16-21 MPa | 16-21 MPa |
| Flow range | 120-150 L/min | 120-150 L/min |
