Rope Silicone Tipping Machine

Request a Quote

Website: http://solution-textile.com/7-2-rope-silicone-tipping-machine.html

Features

• Accurate control of tipping length.
• Adjustable dipping height, frequency, and duration based on different rope requirements.
• Equipped with an automatic height compensation function (approx. 2–10 positions).
• Supports multi-directional dipping motion to prevent crescent-shaped defects.
• Supplied with a complete configuration, including 1 drying rack, 1 rope arranging table, and 20 clamping rods, enabling continuous workflow and improved efficiency.

Parameters

Model	CT-P950
Dimensions	600 (L) × 1300 (W) × 1100 (H) mm
Clamping rod	1000 × 76 × 45 mm
Drive mode	Electric & pneumatic
Air pressure	0.5–0.7 MPa
Total power	2 kW
Power supply	220V / 50Hz

Optional Accessories

• Drying rack:
  2105 × 540 × 1708 mm
  (holds 20 clamping rods)
• Worktable:
  1200 × 600 × 800 mm
• Clamping rods:
  1000 × 76 × 45 mm
