Rope Making Machine
Request a Quote
This rope making machine is designed to make twisted paper rope at high speed, which is auxiliary equipment for paper shopping bag machines with handles. The slit paper is twisted into paper rope with desired diameter, and the twisted paper rope is then rewound to be a paper rope roll for further processing.
Parameters
| Model | ZN-10K | ZN-20K |
| Paper roll core diameter | 76 mm | 76 mm |
| Max. diameter of roll paper | 500 mm | 450 mm |
| Paper roll width | 20-100 mm | 20-100 mm |
| Paper gram | 15-60 g/m2 | 15-60 g/m2 |
| Paper rope diameter | 2.5-6 mm | 2.5-6 mm |
| Production speed | 16-20 m/min | 30-50 m/min |
| Power requirements | 220 V | 220 V |
| Total power | 1.5 kW | 2.2 kW |
| Machine weight | 250 kg | 700 kg |
| Overall dimensions (L*W*H) | 1500*1300*100 mm | 1580*1750*930 mm |
