Hydraulic Notching Machine
Request a Quote
The hydraulic notching machine is available in a fixed structure and adjustable angle structure.
- 4×250
- 6×250
- 4×200
- 6×220
Features
- This machine uses hydraulic drive design to ensure shearing machine stability.
- The entire machine features a steel plate integral welding structure, with an outstanding shear notching rigidity.
- The machine uses centralized lubrication system, which lubricates and protects the machine.
Parameters
| Parameter name | 4×250 | 6×250 | 4×200 | 6×220 | |
| Shearing plate thickness | Common steel mm | 0.5-4.0 | 0.5-6.0 | 0.5-4.0 | 0.5-6.0 |
| stainless steel mm | 0.5-2.0 | 0.5-3.0 | 0.5-2.0 | 0.5-3.0 | |
| Shearing board length mm | 250 | 250 | 200 | 220 | |
| Shearing angle | 90º | 90º | 40º-135º | 30º-140º | |
| number of strokes n/min | ≥35 | ≥35 | ≥35 | ≥30 | |
| bench height mm | 850 | 850 | 850 | 850 | |
| Power of motor kw | 4 | 4 | 3 | 4 | |
| Shape size (length) mm | 910 | 910 | 890 | 950 | |
| Shape size (width)mm | 760 | 810 | 870 | 920 | |
| Shape size(high) mm | 1050 | 1050 | 1080 | 1150 | |
| Weight kg | 680 | 710 | 860 | 970 | |
