Tape Tearing Machine
Request a Quote
Model: AM-CJ-10
JDL tape tearing machine is used to tear off the tape from the painted molded inductors. This machine adopts tray feeding, automatically tear off the tape and collect the waste tape automatically. Color touch screen control allows for simple operation, high efficiency and no damage to the inductor products.
Technical Parameters
| Feeder | Tray feeding |
| Thickness Tolerance | ±0.2mm |
| Length Tolerance | ±0.05mm |
| Temperature Range | ≥200℃ |
| Capacity | 15Kpcs/h |
| Dimensions(mm) | L1300*W1300*H1200mm |
| Air supply | 0.5-0.7Mpa |
| Working environment | -5℃-50℃ (No corrosive gas, harmful gas, flying dust, etc.） |
| Power supply | Single phase AC220V/50HZ |
| Power consumption | 1.5kW |
| Net Weight | 300kg |
