RF231 Assemble Winding Machine
The RF231 assemble winding machine can be used for winding 2 to 4 cotton, wool, and blended yarn into a winding bobbin for use in later processes carried out by a twisting machine.
Spindle gauge: 340mm (2～3 yarns), 370mm (2～4 yarns)
Winding spindle diameter: φ130~φ200mm
Winding spindle: 152mm
Number of spindle: 100 for standard, 10 spindles/pitch (twisting yarns: 2-4); 96 spindles for standard, 10 spindles/pitch (twisting yarns: 2-3)
Max winding speed: 630m/min
Installed power: 0.06W/spindle
Operation mode: double side and single layer
Winding method: random winding
Transmission mode: the guide cam is driven by a single spindle motor via gear
Tension adjustment method: dead load disc pressure type
Breaking yarn monitoring method: auto stop and yarn cutting with infrared ray electronic induction of breaking yarn
Anti-ribboning method: electronic intermittent and guide cam anti-ribboning
- The RF231 assemble winding machine features a simple structure, easy operation, and easy installation and adjustment.
- The operators can set the following functions via the touch screen with the use of a central computer program:
- A. Users can set the yarn production length using the electronic control system
- B. The equipment features an automatic stop after the yarn bobbin is full.
- C. The speed is regulated using a frequency converter.
- D. The winding machine will automatically stop if the yarn breaks.
- E. The fully assembled winding machine can record data.
- F. Users can count the output based on the recorded data.
- G. Optional accessories: balloon separator, air splicer, cleaning device, guide wheel.
