Shielded Inductor Winding Machine
Request a Quote
Model: AM-PBRX-10
The coil winding machine is used for single wire or multi-strand winding on shielded inductor. This shielded inductor winding machine adopts tray feeding, optional in other feeding types. The diameter of wound wire features a range from 0.1m to 0.35mm. The max. production capacity reaches up to 500 pieces/h. The coil winding equipment is designed with a precise counting device and braking device with an alarm system, ensuring precise counting and safe operation.
Product Details:
Technical Parameters
| Application | Shielded inductor |
| Feeder | Pallet/Fixture |
| No. of spindles | 4 |
| Winding method | Winding by spindle rotation |
| Wire size | 0.1m-0.35mm |
| Control system | PLC |
| Capacity | 300-500pcs/h |
| Dimensions(mm) | W1200*W700*H2000mm |
| Air supply | 0.5-0.7Mpa |
| Working environment | 0-50℃(No corrosive gas, dust, etc.） |
| Power supply | Single phase AC220V/50HZ |
| Power consumption | About 3kW |
| Weight | 350kg |
