PLUS-LFHDDBSC330 Multi-Functional Label Finishing Machine
Request a Quote
Plus series digital finishing machine is a customized solution for digital converting and finishing of labels in small or huge quantities. It has the capability to complete all operations in a single run. The user-friendly design combined with high efficiency and superior quality has made this converting equipment a popular choice. Please choose what you want from the table below.
Technical Parameters
| Max. Speed (Semi Rotary Die cut) | 300cycle/min. (≈60m/min.) |
| Max. Full Rotary Speed | 110Meters/min |
| Accuracy of Adhesive Cutting | ±0.15mm |
| Accuracy of IML Cutting | ±0.25mm |
| Max. Die Cutting Area | 330mm×320mm (L×W) |
| Paper Width | 100-330mm |
| Max. Unwinding Dia. | ø700mm (≈2000meters) |
| Max. Rewinding Dia. | ø700mm (≈2000meters) |
| Magnetic Cylinder | 120Teeth 1/8”CP (Standard) |
| Repeat Length of Die Cutting | 50mm~330mm/min. |
| Speed of Hot Laminator (Max.) | 30m~60m/min. |
| Speed of Flexo Printer (Max.) | 110Meters/min. |
| Motor Power | 10kW |
| Overall Diameter (L×W×H) | 2900mm×1200mm×1500mm |
| Weight | 2800KGS |
| Power Supply | AV, 380V, 50HZ, 3 phases, 4 wires |
| Air supply | 100p.s.i |
- Unwinder
1. Closed-loop tension control
2. Machine stops or decelerates when less paper is fed.
3. Automatically controlled web guider with ultrasonic system - Semi-Rotary/Full Rotary Die Cutter
1. Independent servo driver works with mark sensor.
2. Both the magnetic and solid cylinders fit the semi-rotary and full rotary cutting machine.
- Flexo Printer
1. Options: semi-rotary or full rotary mode
2. Applied in cold foil and spot varnishing
3. Compatible with hot air - Rewinder
1. Closed-loop tension control system works with powder clutch, enabling continuous stable tension.
2. The motor slows down as the number of rolls increases.
- Sheeter
1. Independent servo drive
2. Easy set-up function
3. Optional auto collection system - Digital Platform
1. Work with variable data
2. Flexible work
- Liner Razor
1. Quick press for paper slitting
2. Easy adjustment - Hot Laminator
1. Huge size heating roller
2. Stable temperature control
