Flat Panel High Temperature Air Filter, PGHP Series
Request a Quote
Filter elements for battery cell manufacturing
Introducing our flat panel high-temperature air filters, specially designed to ensure air purification in high-temperature environments. Manufactured with low-resistance ultra-fine glass fiber filter paper, separated by aluminum foil, and sealed with high-temperature-resistant adhesive, our air filters offer stability and efficiency in demanding conditions.
Our flat panel high-temperature air filters are ideal for air purification during lithium battery cell production, maintaining high performance even in temperatures of up to 250℃ and 350℃.
Technical Data
| Dimensions | Filter Grade | Rated Air Flow | Initial Resistance at Rated Air Flow | Recommended Air Flow |
| 610x610x150mm | H11 H13 H14 | 1000m³/h | ≤200/235262Pa | 600~1000m³/h |
| 610x457 X150mm | 750m³/h | 450~750m³/h | ||
| 305 x 610x150mm | 500m³/h | 300~500m³/h | ||
| 915x610x150mm | 1500m³/h | 900~1500m³/h | ||
| 1220 x 610 x 150mm | 2000m³/h | 1200~2000m³/h | ||
| 630 x 630 x 220mm | 1500m³/h | 900~1500m³/h | ||
| 945 x 630 x 220mm | 2200m³/h | 1300~2200m³/h | ||
| 1260 x 630x150mm | 2000m³/h | 1200~2000m³/h | ||
| 1260 x 630 x 220mm | 3000m³/h | 1800~3000m³/h | ||
| 610x 610x292mm | 2000m³/h | 1200~2000m³/h | ||
| 305x610x292mm | 1000m³/h | 600~1000m³/h |
- H11 99.5~99.94%@0.3μm
- Test Error of Initial Resistance: ≤15%
- H13 99.95~99.994%@0.3μm
- H14 99.995~99.9994%@0.3μm
Specifications
| Model | PGHP |
| Dimensions | Customizable |
| Frame Material | Galvanized Sheet/304 Stainless Steel/Aluminum Alloy |
| Filter Medium | Ultra-Fine Glass Fiber |
| Separator Material | Aluminum Foil |
| O-ring | Rubber/Silicone |
| Seal Adhesive | High-Temperature Silicone/Glass Fiber Felt |
| Operating Temperature | 150℃/250℃/300℃/350℃ |
| MPPS Efficiency | H13≥99.95%/H14≥99.995% |
Applications
- Ventilation and air conditioning systems in high-humidity conditions and environments with high fire resistance requirements
- Cleanrooms and other environments requiring strict air cleanliness
