Anti-vibration Mount (Yellow)
Request a Quote
This S78-9 yellow anti-vibration mount which is made in line with the standard of JB/T6607-93, is used for the support installation, horizontal adjustment of the machine tool equipment. Our vibration isolation mount could be fixed or movable type.
Parameters of Iton Anti-vibration Mount| Type (mm) | Bolt (mm) | Adjustment Height (mm) | Load per Mount (kgs) |
| φ 40 × 15 | M5 × 30 | 5 | 200 |
| φ 80 × 25 | M10 × 80 | 8 | 500 |
| φ 120 × 32 | M12 × 100 | 12 | 900 |
| φ 160 × 35 | M16 × 120 | 12 | 1300 |
| φ 185 × 40 | M20 × 160 | 12 | 2000 |
| φ 200 × 55 | M22 × 160 | 12 | 4200 |
| φ 250 × 60 | M24 × 180 | 12 | 5000 |
| φ 315 × 70 | M30 × 200 | 12 | 9500 |
