Donut Fryer (Industrial-Grade Fryer with Automatic Flipping)
The flipping fryer is engineered specifically for large-scale production of donuts.
- Capacity: 3,000-10,000 pcs/h
- Product weight: 50-100 g (or customized)
- Product dimensions: 40 mm-100 mm (or customized)
-
The conveyor system utilizes a single-layer mesh belt with an integrated mechanical flipping mechanism. Product discharge is facilitated by a balanced weave belt operating in conjunction with the rod-link belt. A variable frequency drive system provides precise control over conveyor speeds.
-
The fryer features an automated lifting system and heating elements that are secured to the frame, allowing the internal assembly to be raised from the fryer body.
-
The PLC control system manages operational and safety parameters, including frying duration, temperature, oil level, circulation, high-temperature alerts, and dry-burn protection.
-
Safety system, including lifting limit switches and high-temperature alarms, ensures operational security.
-
A liquid level monitoring system tracks standard and minimum oil levels to facilitate ease of operation and maintenance.
