Vacuum Oil Filter
The vacuum oil filters are specifically designed for the fine filtration of frying oil used in breaded, battered, and coated food production.
The vacuum filter utilizes suction to draw high-temperature frying oil from the fryer into a filtration chamber. The oil is purified using filter aids and filter paper before being returned to the fryer.
The filter aid effectively adsorbs free fatty acids, peroxides, high molecular polymers, and suspended particulate impurities.
In addition, the filter paper features optimal porosity and air permeability to isolate particulate impurities and harmful substances larger than 5 microns. This process inhibits the rise of acid value and the generation of peroxides, improving the frying environment and enhancing overall product quality.
DBZL30
| Oil Filtering Capacity | 30L/min |
| Chamber Oil Volume | 70L |
| Filtration Area | 0.62m² |
| Pipe Diameter | Inlet: 1.5 inch Outlet: 1 inch |
| Filter Paper Consumption | 3 sheets/cycle |
| Filter Aid Consumption | 0.4-0.8kg/cycle |
| Power Supply | 1.5kW/380V/50Hz |
| Weight | 160kg |
| Dimensions (L×W×H) | 850×850×1000mm |
DBZL80
| Oil Filtering Capacity | 80L/min |
| Chamber Oil Volume | 124L |
| Filtration Area | 1.2m² |
| Pipe Diameter | Inlet: 2 inch Outlet: 1.5 inch |
| Filter Paper Consumption | 3 sheets/cycle |
| Filter Aid Consumption | 0.8-1.66kg/cycle |
| Power Supply | 3kW/380V/50Hz |
| Weight | 270kg |
| Dimensions (L×W×H) | 1100×1000×1300mm |
DBZL200
| Oil Filtering Capacity | 200L/min |
| Chamber Oil Volume | 194L |
| Filtration Area | 3.18m² |
| Pipe Diameter | Inlet: 3 inch Outlet: 3 inch |
| Filter Paper Consumption | 5sheets/cycle |
| Filter Aid Consumption | 3kg/cycle |
| Power Supply | 5.5kW/380V/50Hz |
| Weight | 450kg |
| Dimensions (L×W×H) | 1250×1200×1400mm |
