Water and Oil Repellent Cartridge Filter Element
When you want to filter dust in high humidity environment, you must need water and oil repellent filter elements and Xin Huan Bao can provide many kinds of water and oil repellent cartridge filter elements. You can directly choose water and oil repellent polyester non-woven fabric as filter material because non-woven fabric can reach water and oil proof effect after processing. But if you have higher demands for filtration efficiency, we can add a layer of PTFE membrane on non-woven fabric, which can not only resist water and oil, but also increase filtration efficiency.
Water and oil repellent non-woven fabric filter elements can be used for the inlet air filtration of gas turbine, air compressor and the dust filtration of various dust removal devices, such as welding fumes and recycling raw materials of production lines of shot blasting, casting, cement, ceramics, steel and chemical industries.
Filter material | Water and oil repellent polyester non-woven fabric |
Bearing back flushing pressure | 4-5KG |
Airflow rate | 100Lm2/sec |
Powder recovery rate | 98.2% |
Filter precision | 8-20μm |
Color | White |
Size | 325mm×215mm×600mm (Optional) |
Top and bottom end cap | Zinc electroplating |
Inside frame diamond mesh | Zinc electroplating |
Bearing temperature | ≤135℃ |
Filter material | TORAY PTFE membrane |
Size (O.D. × I.D.) | O.D. 325mm×I.D. 215mm (220mm), Accept nonstandard customization and sample orders |
Size (Height) | 600mm, 660mm, 900mm, 1200mm |
Dirt holding capacity | 260g/m2 |
Thickness | 0.65mm |
Bearing back flushing pressure | 5-6kg |
Airflow rate | 35Lm2/sec |
Powder recovery rate | 99.8% |
Filter precision | 0.3-0.5μm |
Collecting efficiency/Filter precision | 99.8%/0.5μm |
Top and bottom end cap | Zinc electroplating |
Inside frame diamond mesh | Zinc electroplating |
Air resistance | 8.43mbar When airflow is 70cm/s |
Bearing temperature | ≤135℃ |
Tensile strength | Kgt/5cm MD126.5 CD73 |
You can directly choose from the above displayed water and oil repellent cartridge filter elements. Xin Huan Bao can also meet your requirements for surface treatment method, size and other aspects of filter elements and provide you with custom service for water and oil repellent cartridge filter elements.
If you want to customize other types of filter elements such as pleated filter elements, antistatic cartridge filter elements and laminated cartridge filter elements, you can enter custom page, see custom instructions and provide us with necessary information.
