GT-DJ100 Single Station Benchtop Dispensing Machine
Request a Quote
The single station benchtop dispensing machine is compatible with solder mask, COB black glue, red glue, solder paste, UV adhesive, SILICON, EPOXY, silver glue, AB glue, conducting resin, thermal grease solder paste, instant glue and other kinds of fluid dispensing.
Features
- Functions of drawing points, lines, rectangles, arcs and circles, continuous interpolation of irregular curves and three-axis linkage.
- Overall correction, area correction and area array functions available. Simple machine operations.
- Windows XP Chinese operation interface, easy to learn and operate. 80G hard disk super storage and memory capacity.
- According to customer’s requirements, station locating pin, dispensing syringe fixture and temperature regulating device can be added.
- Double head adjustable syringe fixture available to greatly increase dispensing efficiency.
- 300cc large syringe or glue storage pressure barrel available to save glue replacement time.
Parameters
| Model | GT100/GT200 |
| Work platform (upon request) | 300mm*200mm*60mm/ 480mm*220mm*60mm |
| Drive motor | stepper motor/servo motor(optional) |
| Drive method | imported timing belt/high precision ball screw (optional) |
| Host computer | PC + motion control card |
| Display | 14″ LCD |
| Operation software | Microcomputer control |
| Position precision | 0.01mm |
| Repetition precision | +/-0.005mm |
| Input power | AC220V,50HZ |
Applications
- Semi-conductor packaging
- PCB electronic components fixation and protection
- Loudspeaker adhesive dispensing
- LCD glass plate packaging
- Chip bonding
- Mobile phone dispensing
- Battery box dispensing and bonding
- Hardware parts coating and bonding
- Automobile components coating
- Quantitative gas or liquid coating
