Self Supporting Girder Steel Decking Machine JGH
Self supporting steel deck is a new-type building material. Due to its light structure and high strength, steel deck is increasingly used in steel structure buildings, bridges, and railways, among others. Concrete can be directly poured on the self supporting steel deck, which greatly reduces workload and shortens construction cycle. Jinggong self supporting girder steel decking machine adopts advanced mechanical, electrical, hydraulic and pneumatic technologies. Under microcomputer control, it can automatically complete the whole production process, from steel girder production, bottom plate forming, to steel form assembling and welding. The annual production capacity for single shift achieves 300,000 square meters.

Main Components
Our self supporting girder steel decking machine is composed of steel girder production line, bottom plate forming machine, and steel form spot welder etc.

Technical Specifications for Self Supporting Girder Steel Decking Machine
Equipment name and model Parameter
JGH30 steel girder production line Suitable material Upper chord bar Unribbed deformed steel bar
φ6~14 mm
Lower chord bar Unribbed deformed steel bar
φ5~14 mm
Z-shape additional bar Round steel
φ4~6.5 mm
Finish size Height of upper chord 70~270mm
Height of lower chord 15~30mm(Bending type girder)
0~30mm(Straight type girder)
Length 200~12000mm
Bottom width 135~140mm(Bending type girder)
60, 80 (Straight type girder)
Bottom pitch 200mm
Bottom folding length 30mm
Production speed 10~15m/min
Total power 585 KW
Outline dimensions(LXWXH) 40000mm×5000mm×4500 mm
Total weight About 27T
HG-576 bottom plate forming machine Suitable material Type Galvanized plate
Thickness 0.4~1mm
Forming speed 12~15m
Outline dimensions(LXWXH) 10000mm×1700mm×1000 mm
JGH60 steel form spot welder Suitable workpiece size Width of shaped steel plate 576mm
Max. height of girder 270mm
Workpiece length 1800~12000m
Max. welding speed 5.5m/min
Total power 603KW
Outline dimensions(LXWXH) 19000mm×1700mm×2000 mm

Founded in 1968, Jinggong Science & Technology is a professional manufacturer of self supporting girder steel decking machine in China. A wide range of steel structure machines is available in our company, which includes shot blasting machine, bending machine, digital folder, and drilling machine etc. These have been awarded the ISO9000 and CE certificates. Thanks to their high quality and low prices, our products are exported to many countries, such as America, Australia, Bulgaria, Argentina, Egypt, India, and more. For more information, please feel free to contact us via phone, fax or email.
