JAC-S968SX Ceramic Alumina Flap Discs

Request a Quote

View All: http://indus-abrasives.com/1-1-3-1-ceramic-alumina-flap-discs.html

Availability

Product Code	JAC-S968SX	JAC-S968SX	JAC-S968SX
Abrasive Grains	Premium Ceramic Alumina	Premium Ceramic Alumina	Premium Ceramic Alumina
Flap Disc Density	Standard	Standard	Standard
Flap Fitted Versions	Single / Double	Single / Double	Single / Double
Backing Plate Material	Reinforced Fiberglass	Reinforced Nylon	Turbo-Cooling Trim Plastic
Flap Disc Shape Available	T29-Conical / T28-Convex / T27-Flat	T29-Conical / T28-Convex / T27-Flat	T29-Conical / T27-Flat

BRITSH SIZE	METRIC SIZE	GRIT	MAX	STD	PART #			PART #			PART #
( D x H )	( D x H )	GRIT	RPM	PACK	T27	T28	T29	T27	T28	T29	T27	T28	T29
4" x 5/8"	100 mm x 16 mm	36	15,300	10	96001	97569	96002	96730	97872	96731
		40			96014	97572	96015	96743	97885	96744
		50			96027	97585	96028	96756	97898	96757
		60			96030	97598	96031	96769	97901	96860
		80			96043	97601	96044	96872	97914	96873
		100			96056	97614	96057	96885	97927	96886
		120			96069	97627	96060	96898	97930	96899
4-1/2" x 7/8"	115 mm x 22.23 mm	36	13,300	10	96072	97730	96073	96901	97943	96902	97114		97115
		40			96085	97743	96086	96914	97956	96915	97127		97128
		50			96098	97756	96099	96927	97969	96928	97130		97131
		60			96101	97769	96102	96930	97972	96931	97143		97144
		80			96114	97772	96115	96943	97985	96944	97156		97157
		100			96127	97785	96128	96956	97998	96957	97169		97160
		120			96130	97798	96131	96969	98001	96960	97172		97173
5" x 7/8"	125 mm x 22.23 mm	36	12,200	10	96143	97801	96144	96972	98014	96973	97185		97186
		40			96156	97814	96157	96985	98027	96986	97198		97199
		50			96169	97827	96160	96998	98030	96999	97301		97302
		60			96172	97830	96173	97001	98043	97002	97314		97315
		80			96185	97843	96186	97014	98056	97015	97327		97328
		100			96198	97856	96199	97027	98069	97028	97330		97331
		120			96201	97869	96202	97030	98172	97031	97343		97344
6" x 7/8"	150 mm x 22.23 mm	36	10,200	10	96214		96215
		40			96227		96228
		50			96230		96231
		60			96243		96244
		80			96256		96257
		100			96269		96260
		120			96272		96273
7" x 7/8"	180 mm x 22.23 mm	36	8,600	10	96285		96286	97043		97044	97356		97357
		40			96298		96299	97056		97057	97369		97360
		50			96301		96302	97069		97060	97372		97373
		60			96314		96315	97072		97073	97385		97386
		80			96327		96328	97085		97086	97398		97399
		100			96430		96431	97098		97099	97401		97402
		120			96443		96444	97101		97102	97414		97415
4-1/2" x 5/8"-11	115 mm x M14-2	36	13,300	5	96456		96457				97427		97428
		40			96469		96460				97430		97431
		50			96472		96473				97443		97444
		60			96485		96486				97456		97457
		80			96498		96499				97469		97460
		100			96501		96502				97472		97473
		120			96514		96515				97485		97486
5" x 5/8"-11	125 mm x M14-2	36	12,200	5	96527		96528				97498		97499
		40			96530		96531				97501		97502
		50			96543		96544				97514		97515
		60			96556		96557				97527		97528
		80			96569		96560				97530		97531
		100			96572		96573				97543		97544
		120			96585		96586				97556		97557
6" x 5/8"-11	150 mm x 5/8"-11	36	10,200	5	96598		96599
		40			96601		96602
		50			96614		96615
		60			96627		96628
		80			96630		96631
		100			96643		96644
		120			96656		96657
7" x 5/8"-11	180 mm x 5/8"-11	36	8,600	5	96669		96660
		40			96672		96673
		50			96685		96686
		60			96698		96699
		80			96701		96702
		100			96714		96715
		120			96727		96728
