Mini Excavator SWE25UF
- Operating weight: 2.65t
- Standard bucket capacity: 0.08m³
- Rated power: 14.6kW/2400rpm
Mini Excavator, SWE25UF
Request a Quote
Yanmar engine: due to low noise level and reduced vibration, as well as easy maintenance of main engine components, this engine is trustful for using in compact construction machinery;
Spacious & comfortable cab: expended glass area of front window and skylight, high grade air suspension seat, faux leather interior design, radio, cup holder and reading light, delivering great comfort for the operator;
Easy maintenance: a fully opening hood and orderly arranged internal parts allow for quick and easy daily checking and filter changing; The service door is located at the side for quick access and easy maintenance of control valve, eliminating the need for remove other parts;
Technical Specifications
| Type of cab | Cabin/Canopy | ||
| Bucket capacity, std. | m³ | 0.08 | |
| Bucket width | mm | 580 | |
| Operating weight | kg | 2650/2550 | |
| Dimensions | Overall length | mm | 4140 |
| Overall height | mm | 2455 | |
| Overall width | mm | 1500 | |
| Ground clearance | mm | 310 | |
| Engine | Brand | Yanmar | |
| Model | 3TNV80F-SPSU | ||
| Displacement | L | 1.267 | |
| Output | kW/rpm | 14.6/2400 | |
| Working range | Max. cutting height | mm | 4355 |
| Max. loading height | mm | 3010 | |
| Max. digging depth | mm | 2840 | |
| Max. vertical wall digging depth | mm | 2580 | |
| Max. digging reach | mm | 4775 | |
| Boom swing angle (left/right) | ° | 65/50 | |
| Front swing radius | mm | 1980 | |
| Tail swing radius | mm | 765 | |
| Max. digging force (arm) | kN | 14 | |
| Max. digging force (bucket) | kN | 24 | |
| Track | Type | Rubber track/steel track | |
| Track width | mm | 300 | |
| Track length | mm | 1990 | |
| Undercarriage | Length to center of rollers | mm | 1560 |
| Length to center of track | mm | 1200 | |
| Travel speed (high/low) | km/h | 4.4/2.6 | |
| Gradeability | ° | 30 | |
| Swing speed | rpm | 10 | |
| Ground pressure | kpa | 25.1 | |
| Blade | Width | mm | 1500 |
| Height | mm | 325 | |
| Max. lift above ground/drop below ground | mm | 330/320 | |
| Hydraulic pump | Type | 2 variable plunger pump, 1 gear pump | |
| Displacement | L/min | 2×28.8 19.2 6.5 | |
| Hydraulic pressure | MPa | 2×23.5 19 | |
| Fuel tank capacity | L | 24.6 | |
| Hydraulic oil tank capacity | L | 18.6 | |
Statement of technical specification: all parameters above are subject to change due to the continuous improvement of the product, please to get the latest info updates.
