Four-Color Label Printer

Request a Quote

View All: http://upg-printpacking.com/1-1-4-four-color-label-printer.html

LQ-MD 330M

Industrial label printing machine

This newly developed industrial roll label printer enhances productivity thanks to its manual shaft expansion and a ruler for rewinding and unwinding, which facilitates quick and easy loading and unloading. The operation is streamlined, saving significant steps and time. The entire printing machine is constructed with a precise processing frame to ensure the parallelism of the paper feeding axis and the neatness of the winding and unwinding end faces. Integrated with a standard RIP system and autonomous operation software, the label printer optimizes most images and prints quickly.

Applications

Specifications

Model	LQ-MD 330M
Ink Type	Water-based dye/pigment ink (CMYK)
Ink Cartridge Capacity	1000ml ×4 colors
Printhead Model	GR-297 (HP A3)
Number of Printheads	1
Resolution	1200×600/1200×1200dpi
Print Speed	18m/min (1200×600dpi) 9m/min (1200×1200dpi)
Print Width	297mm
Max. Media Width	330mm
Max. Roll Diameter	300mm
Max. Media Thickness	0.5mm
Working Environment	Temperature: 15-35°C Relative Humidity: 50%-70%
Dimensions	885×835×1335mm

Features

The printer uses inks that are safe for the environment, with large tanks that hold 900ml of ink per color. It also has extra tanks with sensors to make sure you always have a steady supply of ink. This setup means you can print for a long time without needing to refill the ink, and it helps keep your workspace clean and green.
This label printer is fast, printing up to 18 meters of labels per minute. It also prints clear images, with a resolution of 1200×1200 dpi. This means your labels will have sharp text and bright, vivid colors, perfect for all kinds of uses from marketing to product labels.
The label printing machine has a smart system that adjusts how it handles paper based on its weight. This keeps the paper feeding smoothly, so the operators do not need to worry about paper jamming or uneven printing. This is great for printing on different kinds of paper, from thin labels to thicker materials.
With built-in RIP software and smart operation features, our label printer prints images ready quickly and efficiently. This means it is possible print complex designs fast and accurately, making your workflow smoother and more productive.
