Four Column Hydraulic Press Manufacturer

Four Column Hydraulic Press

Request a Quote

View All: http://wheel-machinery.com/2-3-3-4-post-hydraulic-presses.html

Four column hydraulic press are widely used in wheel disc and rim, and lock ring/flange ring manufacturing to carry out forming, planishing, expansion, punching, feeding, and other processes. Based on machine features, they are also used for strengthening, blanking (optional buffer device), bending, flanging, cold extruding, and other metal material punching processes simply by switching to different tools. Other functions include levelling, press-fitting, powder compression forming, abrasive product forming, and formation of plastic products and insulating materials.

Features

The 3-beam and 4 post structure is both economical and practical.
The hydraulic control uses a cartridge valve integrated system, thereby reducing leak points and guaranteeing a reliable operation and long service life.
Two forming processes are achievable: fixed-stroke and fixed-pressure. This ensures pressure maintenance and time delay, with an adjustable time delay.
The working pressure and stroke are adjustable within the specified range.
Button centralized control is used.
For steel wheel rim flaring and expanding processes, a press with the corresponding tonnage is used.

Optional accessories or functions

Movable table
Punching buffer device
Photo-electricity protection device
Travel, pressure, speed digital display and control device
Touch industrial display screen
Hydraulic heating, cooling device
Punching device
Sliding block safety locking pin
Temperature controller for die heating machine
PLC

Technical parameters

Project		Unit	Model
Project		Unit	YD32-315（K)	YD32-315D	YD32-315B	YD32-315C	YD32-400	YD32-400A	YD32-500	YD32-500（K)	YD32-500F	YD32-500B	YD32-500C	YD32-500D	YD32-630
Nominal force		kN	3150	3150	3150	3150	4000	4000	5000	5000	5000	5000	5000	5000	6300
Ejection force		kN	400	400	--	400	630	--	1000	1000	1000	1000	1000	--	1000
Slider Stroke		mm	900	900	800	800	800	800	900	900	900	900	900	900	900
Ejection stroke		mm	250	250	--	250	250	--	350	350	350	350	350	--	350
Open height		mm	1250	1250	1250	1250	1250	1250	1500	1500	1500	1500	1500	1800	1500
Slider speed	Idle descending	mm/s	250	250	100	250	120	120	150	250	250	250	250	250	250
	Processing	mm/s	6-15	6-15	4-10	6-15	4-10	4-10	5-12	8-18	8-20	8-20	8-20	8-20	8-16
	Return stroke	mm/s	150	150	80	150	90	90	120	170	170	160	160	160	150
Ejection Speed	Ejection	mm/s	120	120	--	120	120	--	80	100	100	80	80	--	100
Ejection Speed	Return	mm/s	180	180	--	180	180	--	220	240	240	220	220	--	240
Work tabledimensions	Left-Right	mm	1260	1400	2000	1500	1240	2000	1400	1400	1600	2000	2200	2600	1420
Work tabledimensions	Front-Back	mm	1160	1400	1500	1200	1200	1500	1400	1400	1400	1400	1500	1800	1400
Machine size	Left-Right	mm	3500	3500	2900	3200	3300	3100	3800	3800	3800	4500	4800	5500	4500
	Front-Back	mm	2150	2150	2200	2400	2200	2400	3500	3500	3500	3500	3500	3700	3300
	Height above ground	mm	5000	5000	5100	5100	4600	5200	5300	5300	5300	5300	5300	5700	6000
Motor power		kW	22	22	22	22	22	22	44	45	45	45	45	45	45
Remarks			Fast	Fast	Fast					Fast	Fast	Fast	Fast		Fast

Project		Unit	Model
Project		Unit	YD32-1250	YD32-1250B	YD32-1250C	YD32-1500	YD32-1600	YD32-1600A	YD32-2000	YD32-2000A	YD32-2500	YD32-3000	YD32-3600	YD32-5000	YD32-6000
Nominal force		kN	12500	12500	12500	15000	16000	16000	20000	20000	25000	30000	36000	50000	60000
Ejection force		kN	1000	1000	1000	1000	1600	2000	2000	--	--	2000	8000	1600	--
Slider stroke		mm	700	900	1000	1200	900	1000	900	900	1200	2500	2000	1500	2000
Ejection stroke		mm	350	350	350	350	350	400	300	--	--	350	700	350	--
Open height		mm	1300	1500	1600	2800	1500	1800	1600	1800	2500	3500	4000	2300	4000
slider speed	Idle descending	mm/s	250	250	150	150	250	200	150	150	150	200	150	150	150
	Processing	mm/s	8-16	8-16	6-12	4-10	8-16	5-12	4-10	8-16	5-12	5-10	5-12	5-12	6-12
	Return stroke	mm/s	200	200	100	120	200	150	120	150	120	150	120	120	120
Ejection Speed	Ejection	mm/s	100	100	100	100	60	50	60	--	--	100	--	100	--
Ejection Speed	Return	mm/s	200	200	200	200	130	80	120	--	--	200	--	200	--
Work tabledimensions	Left-Right	mm	1500	1800	2800	3500	1600	2500	2000	3600	2800	4000	5000	4000	6000
Work tabledimensions	Front-Back	mm	1200	1600	2000	2650	1600	1800	1800	2400	2400	3000	3500	3000	2000
Machine size	Left-Right	mm	4900	5500	5000	5700	7500	8300	8000	7600	3650	9100	3650	15000	15500
	Front-Back	mm	2800	3200	2900	3900	3000	3000	2900	3200	5900	6500	5900	8500	9500
	Height above ground	mm	6300	5700	6500	8200	6800	6925	7660	7500	7530	115000	11500	8500	12500
Motor power		kW	95	99	92	82	140	91	95	180	160	150	290	350	400
Remarks				Fast									Mobile station
