LQ-MD 108/216/330

Digital UV label printers from this series are designed for short-run, variable-data, and on-demand label production. They combine high-resolution digital printing with UV curing to deliver fast-drying, long-lasting results on materials such as coated paper and synthetic films. With available printing widths of 108mm, 216mm, and 330mm, they adapt to various formats and production needs. These printing machines are ideal for businesses aiming to expand their digital printing capabilities or complement existing analog lines, offering low setup time, consistent output, and cost-effective production for customized and small-batch labels in various industries such as food, cosmetics, and logistics.

Applications

Wine labels
Wine labels
Cosmetics labels
Cosmetics labels
Food label
Food label

Specifications

Model	108	216	330
Print Technology	DOD Piezoelectric Inkjet, Kyocera Printhead
Print Width	108 mm	216 mm	314 mm
Ink Type	LED-UV Curable Ink
Print Resolution	600×600 dpi / 600×900 dpi / 600×1200 dpi
Number of Printheads	4 (expandable)	8 (expandable)	12 (expandable)
Print Speed	Up to 50 m/min (164 ft/min)
Color Configuration	CMYK (expandable to White, Varnish, or White Varnish)
Ink Tank Capacity	3 L
Software & Interface	Label Print Control Software, PrintFactory RIP Software
Core Diameter	76.2 mm (3″)
Max. Web Width	230 mm	250 mm	380 mm
Max. Roll Diameter	500 mm	600 mm	700 mm
Pre-Curing Method	Air-Cooled LED
Final Curing Method	Water-Cooled LED
Max. Media Width	230 mm	250 mm	350 mm
Compatible Media Types	Coated and uncoated paper, PP, PVC, BOPP, etc.
Material Thickness	0.08–0.5 mm (0.003–0.02″)
Operating Environment	Temperature: 15–30 ℃ (59–86 ℉); Relative Humidity: 40–60% (recommended)
Power Supply	220V 30A (Single-phase)	380V 40A (Three-phase)	380V 50A (Three-phase)
Air Supply	6–8 bar, clean and dry
Dimensions (L×W×H)	2000×1300×1850 mm	3360×1600×2200 mm	3500×1750×1850 mm
Machine Weight	1430 kg	2400 kg	2700 kg

Features

High-resolution, high-speed DOD piezoelectric inkjet printheads suitable for industrial use
Support for variable data printing, ideal for personalized and short-run jobs
Digital varnish printing capability for enhanced surface effects and protection
Automatic printhead maintenance system for consistent performance and reduced downtime
Modular design allows integration with optional units such as cold foil and cutting systems

Machine Components

Unwinder
Equipped with an electronic web guiding system to ensure precise material alignment during feeding. The label printer includes a 76.2 mm (3") servo-driven unwind shaft with magnetic particle clutch, providing stable tension control and smooth unwinding throughout the printing process.
Web Cleaner
Effectively removes dust, paper particles, powders, and other visible contaminants to ensure consistent quality, reduce waste, and maintain stable printing with no downtime.
Corona Treatment & Tension Control System
Prepares the surface of the substrate by increasing its surface energy, allowing inks to adhere more effectively during printing. Combined with a precise closed-loop tension control mechanism, it ensures smooth media handling, consistent ink droplet placement, and stable print quality even at high speeds.
UV-LED Pinning Unit
“Freezes” ink droplets before overlaying subsequent colors or full curing, helping to control dot gain and maintain color accuracy.
Print Head Cleaning Module
Designed for ease of maintenance and minimal downtime, the cleaning system automates purging, wiping, and capping tasks. This ensures consistent print quality while enabling unattended operation.
Integrated Ink Supply and Nagtive Pressure System
Managed through a PLC system, the ink supply and negative pressure unit maintain stable ink flow, contributing to print consistency across long runs and helping prevent ink interruptions.
Rewinder
Features a 76.2 mm (3") servo-driven spindle equipped with a magnetic particle clutch and a closed-loop tension control system. Supports a maximum rewind diameter of 600 mm (23.6"), providing smooth and accurate media winding.
Media Rewinding System
Dual servo motors and a precision tension control mechanism ensure neat, uniform rewinding, which is particularly useful when rerunning partially used rolls.
Printhead Alignment Control
The print module can be digitally repositioned across the full 380 mm media width using software settings. This feature ensures accurate alignment for different label layouts without the need to manually reposition the substrate.
Variable Date Printing
Built to support short-run, customized production with variable data output. Compatible with a range of applications including labels, hangtags, tickets, RFID tags, and foil-based packaging.
Varnish/Foil Module（Optional）
Offers additional finishing options such as varnish or foil printing to enhance the visual and tactile appeal of labels. Suitable for creating distinctive effects that help products stand out on shelves.
