  • JW1512 Mechanical Adjustable Polarizer
JW1512
In-line fiber optic polarizer with adjustable polarizer holder

This polarizer utilizes Corning's Polarcor™ all-glass polarizing plates to convert input light into linearly polarized light. It features a high extinction ratio and low insertion loss, making it suitable for a variety of precision polarization measurements. With 360-degree adjustability, it can accommodate diverse polarization state measurement needs, such as monitoring polarization state changes over time, testing polarization extinction ratio (PER), and configuring variable beam splitters.

Specifications
Wavelength 850/1064/1310nm
Insertion Loss ≤5dB (without polarizing glass)
Insertion Loss Adjustment X-axis/Y-axis adjustable
Optical Connector Type FC/PC or FC/APC (default PC)
Extinction Ratio >40dB
Rotation 360°
Dimensions 60×36×72mm
