Digital Logo Printer
Our digital logo printers are designed for fast and precise printing on glass surfaces. They support custom logos, patterns, images, text, and variable codes, making them suitable for branding, labeling, and product traceability across different industries.
Each digital printing system is controlled through dedicated software and includes key components such as a computer interface, print control board, ink circulation system, operation panel, motion control unit, and image capture module. They’re equipped with high-precision industrial printheads imported from leading manufacturers, offering high firing frequency, long service life, and print resolutions of up to 600 dpi.
With a specially designed ink circulation system that prevents clogging, these glass printing machines can handle variable data printing with ease. They're a great fit for projects that involve unique code printing on each item or require frequent updates to logo designs across different glass products.
| Model | BWDP-0510 |
| Max. printing area (mm) | 100 × 50 |
| Min. printing area (mm) | 0.4 × 0.4 |
| Number of printheads | 1 |
| Drop size (pL) | 7 / 14 / 21 |
| Ink color | Black, White (single-color printing) |
| Printing resolution (dpi) | 720 × 600 |
| Printing speed (mm/s) | 100 |
| Max. glass size (mm) | 1200 × 1800 |
| Min. glass size (mm) | 300 × 300 |
| Glass thickness range (mm) | 3–30 |
| Ink type | High-temperature eco-friendly ink for glass |
The printhead can move along the X, Y, and Z axes, allowing flexible adjustment to match different glass sizes and print positions within the working area.
It supports a print area of up to 100 × 54 mm, which is ideal for logos, small labels, or localized markings on glass surfaces.
Both static and inline printing modes are available, so you can choose the most suitable option based on your production flow.
