RTTP-200A Digital Belt Textile Printer

RTTP-200A Digital Belt Textile Printer
Request a Quote

Basic information:
Print head: KONICA REVO-S
Max printing speed: 400㎡/hr
Max printing width: 1.8M (72inch)
Max fabric thickness: 10mm

Introduction:
The RTTP-200A digital belt textile printer is an industrial grade digital belt textile printer that is known for its highly accurate and fast performance.

Application:
The RTTP-200A Digital Belt Textile Printer is widely used in domestic digital fabric printing, personalized fashion printing, underwear printing, gift printing, professional proofing and other areas.

Product features:
1. The Japanese Konica industrial-strength textile print head is designed to carry out large scale, continuous printing.

2. The RTTP-200A Digital Belt Textile Printer is equipped with a heating system, which allows the print head to work under any circumstance.

3. The collision prevention system on the printer protects the print head against the printing materials.

4.The detection system effectively monitors the applique level in real time to protect the print head from being scratched.

5. The infrared testing system will monitor the applique level in real time in order to protect the print head.

6. The flexible pressure roller assembly ensures the flatness of the applique during the printing process.

7. The automatic ink absorption system directly cleans and preserves the print head in such a way that is safe and convenient.

8. The belt is automatically cleaned.

9. The negative pressure ink supply system ensures continuous ink release for smooth printing during the printing process.

Parameters:
Textile printer:
Model RTTP-200A
Technology Drop on-demand piezo inkjet technology
Printhead & Standard Konica REVO-S x 16pcs/8pcs/4pcs
Ink Type Pigment Ink
Maximum Printing Width 1.8m(72inch)
Max Fabric Thickness 10mm
Printing Speed Draft 400 ㎡/h
Standard 290 ㎡/h
Ultra 180 ㎡/h
Operating Environment Mechanical Operating Condition 15~30 ℃ 40~70% RH
Inkjet Supplement Control Condition 20~28 ℃ 40~70% RH
Maintenance of Printhead Auto Maintenance System
Ink Supply System Motor-driven pump supply
Fabric Feeding System Annular belt fabric feeding system
Belt Cleaning Continual water brush roller cleaning mode. Output of supplying water is 7~8 L/min.
Compressed Air Using Standard Above 5 kgf/cm³ Above 1.5 hPa
Dimensions W 4400 x L 2400 x H 1660 (mm)
Weight Approx. 2500 kg
Power Supply Three-phase 380 V
Electrothermal tunnel drying oven:
Mesh Belt Width 2250 mm
Temperature Control System Solid Relay Control
Electric Heating Power 50 KW, 380 V
Circulating Fan Power 1.5 KW
Temperature Range Indoor┄200 ℃
Dimensions W 2720 × L 5500 × H 1550 (mm)

Our company is a leading digital belt textile printer manufacturer and supplier in China, we are offering printing equipment such industrial printers, commercial printers, these printing machines are widely used in poster printing and banner printing, and can print different printing materials like paper, textile, and we have rich experience of manufacturing large format printers, we are confident to offer any client good quality digital printing machines with reasonable price.
