Compare with traditional DXD300 wrapper, DXD300 servo flow wrapper is controlled by servomotor, which brings stable convey belt speed, good package integrity and high productivity. In addition, The improved DXD300 plus servo flow wrapper can realize the old and new film connection smoothly without stopping the machine, thus reduce the time of film replacement greatly improve efficiency. What’s more, DXD300 plus adopts PC control screen, which makes operators easier to use. Therefore, the operation training is needless.

DXD300 servo flow wrapper adopts up-film packing form. Varieties of composite films are available to package deckle-edge products and products with crumbs or burrs such as biscuit. Moreover, DXD300 plus could package single or multiple products of various types including biscuit, chocolate, and cakes as well as cards, daily necessities, etc.

Technical Parameters
Max. Production Capacity 30-140bags/min(Single Cutter) 80-290(Double Cutter) 80-350(Three Cutter)
Shape of products Square, rectangle, circular, ellipse and flake etc.
Packaging Range Bag Length 170-400mm 80-300mm Packaging Range
Width 35-100mm
Height < 60mm < 40mm
Max Width of Film 300mm
Max. Dia of Film Ø350mm
Gross Power 3Kw
Power Supply 220V 50Hz
Gross Weight 900kg
Overall Dimension 4300×850×1550mm
