GE2268 Tricot Machine

High speed textile machine for the production of simple warp knitted fabrics

Tricot warp knitting machine is a high-speed textile machinery commonly used to weave relatively simple warp knitted fabrics. Tricot warp knitting machines typically use 2 to 4 guide bars, resulting in high production efficiency. It is a popular textile weaving equipment.

Processing materials

Clothing fabrics, wool, nylon silk, polyester silk, cotton silk, natural silk

Applications

Home textiles such as mosquito nets, curtains, tablecloths, and mattress sheets

Features
  • Tricot warp knitting machine adopts an optimized crankshaft connecting rod transmission mechanism.
  • The knitting elements are made of carbon fiber profiles, featuring light weight, low inertial mass, stability and reliability.
Specifications
  • Needle type Compound needle
  • Gauge E28, E32
  • Number of bars 2/3/4 bars
  • Working width 186"/218"/238"/290"
  • Max. speed 1600-2400 rpm (depending on fabric)
Machine Model Dimensions (L×W×H) Floor Area (m²) Machine Weight (kg) 380V Total Power (kW)
GE2268-186" 6745×2600×2620 17.5 7000 16
GE2268-218" 7565×2600×2620 19.7 8000 16
GE2268-238" 8065×2600×2620 21 9000 19.5
GE2268-290" 9000×2650×2760 23.85 15000 19.5
