GE2888 Raschel Machine

Double needle bar raschel knitting machine for producing blankets, plush toys and plush fabrics

Applications

Blankets and plush fabrics used in apparel, blankets, plush toys, etc.

Features
  • Blanke warp knitting machine uses an oil immersed cam-linkage mechanism and fixed ground bars.
  • Raschel warp knitting machine has functions of electronic yarn let-off, electronic fabric take-up and electronic guide bar control (EL).
  • The plush has a pile height of 5-25mm.
Specifications
  • Needle type Individual latch needle, block latch needle
  • Gauge E16, E18, E22
  • Number of bars 5 bars
  • Distance between knocking-over bar 10-50mm
  • Working width 90"/100"/110"/138"/170"
  • Max. speed 850 rpm
Machine Model Dimensions (L×W×H) Floor Area (m²) Machine Weight (kg) Total Power (kW)
GE2888-90" 3510×6400×3880 22.4 8000 9
GE2888-100" 3760×6400×3880 24.1 8500 9
GE2888-110" 4160×6400×3880 26.62 10000 10
GE2888-138" 4900×6400×3880 31.4 11500 10.25
GE2888-170" 6100×6400×3880 39 13500 15.5
