High Precision CO2 Laser Cutting Machine, CMA0604-G-A/CMA1008-G-A
Request a Quote
- The high precision CO2 laser cutting machine adopts screw motion system which uses famous servo motor with high inertia and high torque to ensure high speed and high precision running of the machine.
- The screw motion can greatly improve cutting efficiency.
- There are optional cellular board worktable and blade worktable for different material to be cut.
- High-rigidity machine body which adopts sheet metal bending and welding can ensure the stable running of cutting machine by matching with self-developed system from Han’s Laser.
- This cutter uses homemade superior laser tube which features good facula quality because of stable output power.
| Model | CMA0604-G-A | CMA1008-G-A |
| Laser power (W) | 60-130 | |
| Drive system | Screw module | |
| Cutting range (mm) | 600*400 | 1000*800 |
| Overall dimension (mm) | 1530 × 1046 × 1070 | 1820 × 1495 × 1190 |
| Speed (m/min) | 30 | |
| Repeated positioning accuracy (mm) | ±0.1 | ±0.5 |
| Supply voltage | 220V/50Hz | |
| Total power（Kw） | 1.7 | 1.5 |
| Working environment | Temp: 5 ~4 0 ℃ Humidity: 5 ~8 0 %, Clean | |
Application
The high precision CO2 laser cutting machine can be applied for non-metal cutting of electronic accessories and mobile phone accessories in electronic industry.
