6x4 BEV Tractor Unit (Genlyon)

6x4 BEV Tractor Unit (Genlyon)
Request a Quote

Heavy Duty Truck Manufacturer in China

Offer tractor unit, dump truck, cargo truck, concrete mixer truck, bulk cement truck, tanker truck, etc.

Technical Parameters
Model
Driving type 6x4
Vehicle kerb weight (kg) 11000
Gross vehicle weight (kg) 18000
GCW (Gross Combination Weight) (kg) 44000
Maximum speed (km/h) 90
Wheelbase (mm) 3850 1400
Driver's cabin High roof cab with twin sleeper
Exterior dimension (mm) Length 7460
Weight 2550
Height 3860
Engine Model CRRC TZ400XS035
Power (kW) 360
Torque (Nm) 2800
Gearbox FAST® 6E240
Battery CATL 282kWh
Front axle 5.5T
Drive axle HY420
Tire 12R22.5
Fifth wheels JOST 50
Frame Single frame
Optional Driver's cabin Flat roof cab with one sleeper
Front axle 6,5T
Tire 315/70 R22.5, 295/80 R22.5
*This model can be customized for right-hand drive.
The parameters above are for reference only. Contact us for more specific configurations.
