kHz 1.5µm Narrow Linewidth Single Frequency Fiber Laser

kHz 1.5µm Narrow Linewidth Single Frequency Fiber Laser
kHz 1.5µm Narrow Linewidth Single Frequency Fiber Laser
Request a Quote

Fiber laser components, Industrial laser solutions

The CKSF-R narrow linewidth single frequency fiber laser offers linewidth below kHz level, features ultra-low phase noise and relative intensity noise (RIN), and the side-mode suppression ratio (SMSR) is over 55dB. The output power is at mW level, and higher output power can be tailored to your specific needs. The wavelength is available in range of 1530-1575nm.

The CKSF-D single frequency fiber laser is a kind of ultra-low noise fiber lasers which are designed with distributed feedback bragg grating type fiber laser technology, achieving stable linear polarization, single longitudinal mode and ultra-narrow linewidth single-frequency laser output. The output optical spectrum linewidth is at kHz level, featuring ultra-low phase noise and intensity noise, with strong capability of environment interference resistance. The output power can be over 100mW.

CKSF-D-ER-M: utilizing erbium-doped fiber, ultra-narrow linewidth <1kHz, low phase noise
CKSF-D-EY-M: utilizing erbium–ytterbium co-doped fiber, linewidth <15kHz, low relative intensity noise (RIN)

1.5µm Narrow Linewidth Single Frequency Fiber Laser, CKSF-R
Features
  • Ultra-narrow linewidth
  • Stable single-frequency & single polarization operation
  • Free of mode-hops, no bursting noise
  • Low phase noise and low relative intensity noise
  • Flexible design, multiple wavelengths are optional
  • Linear polarization output, high polarization extinction ratio (PER)
  • Small size, robust package
Applications
  • Fiber optic sensing
  • LiDAR
  • Hydrophone
  • Laser spectroscopy
  • Coherent communication
  • Other scientific research tasks
1.5µm Narrow Linewidth Single Frequency Fiber Laser, CKSF-D
Features
  • Ultra-narrow linewidth
  • Stable single-frequency & single polarization operation
  • Free of mode-hops, no bursting noise
  • Low phase noise and low relative intensity noise
  • Flexible design, multiple wavelengths are optional
  • Linear polarization output, high polarization extinction ratio (PER)
  • Small size, robust package
Applications
  • Fiber optic sensing
  • LiDAR
  • Hydrophone
  • Laser spectroscopy
  • Coherent communication
  • Gas absorption measurement
  • Other scientific research tasks
Specifications
Parameter Unit Specification
Typ. Typ.
Part no. CKLIS-D-ER-M CKLIS-D-EY-M
Center wavelength nm 1530-1570nm
Output power mW 5-100
Laser emission CW, Single frequency & Single longitudinal mode
Beam quality < 1.05
Linewidth kHz < 1 < 10
OSNR(50pm resolution) dB >50(typical>55dB) >55(typical>60dB)
Relaxation oscillation peak frequency kHz ~600 ~800
Relative intensity noise(RIN) peak dB/Hz -100 -110
Relative intensity noise(RIN) dB/Hz 23
Output power stability % < 1
Wavelength thermal tuning range nm >0.7 >0.8
Fast PZT modulation Optional
PZT modulation frequency kHz DC-20kHz
Output isolation dB 30
Operating voltage V 12VDC
Output fiber type PM1550-XP
Output fiber length m >0.5
Optical connector FC/APC
Output fiber for monitor Optional
Interface RS485
Operating temperature 5-60
Storage temperature -85
Dimension mm 175(L)×130(W)×30(H)
145(L)×100(W)×25(H)
