80mm 25W Speed Control Motor

Request a Quote

View All: http://zd-drivers.com/1-2-3-speed-control-ac-gear-motor.html

Motor Specifications

Model	Output Power W	Voltage V	Frequency Hz	Speed Control Range r/min	Allowance Torque		Starting Torque mN.m	Current A	Capacitor μF
					1200r/min m N.m	90r/min mN.m
4IK25RGN-A	25	1ph 100	50	90～1400	190	47	88	0.50	8.0
			60	90～1700				0.55
4IK25RGN-E	25	1ph 110	60	90～1700	190	50	105	0.45	7.0
		1ph 120						0.50
4IK25RGN-C	25	1ph 220	50	90～1400	190	47	88	0.25	1.8
		1ph 230						0.23
4IK25RGN-H	25	1ph 220	60	90～1700	190	45	88	0.23	1.8
		1ph 230

Gear Motor-Torque TableAllowance Torque Unit: N.m

Type Motor/Gearhead		Gear Ratio		7.5	9	12.5	15	18	25	30	36	50	60	75	90	100	120	150	180
		Speed r/min	50Hz	200	166	120	100	83	60	50	41	30	25	20	16	15	12	10	8
		Speed r/min	60Hz	240	200	144	120	100	72	60	50	36	30	24	20	18	15	12	10
4IK25RGN-A 4IK25RGN-E 4IK25RGN-C 4IK25RGN-H	4GN()RC 4GN()RT	Allowance Torque	50Hz	0.99	1.18	1.64	1.97	2.37	3.29	3.95	4.73	6.58	7.10	8.00	8.00	8.00	8.00	8.00	8.00
4IK25RGN-A 4IK25RGN-E 4IK25RGN-C 4IK25RGN-H	4GN()RC 4GN()RT	Allowance Torque	60Hz	0.80	0.95	1.33	1.59	1.91	2.65	3.18	3.82	5.30	5.73	7.16	8.00	8.00	8.00	8.00	8.00
