Multiple Cylinder Hydraulic Cone Crusher, YHP Series
Request a Quote
Yate YHP series multiple cylinder hydraulic cone crusher is an excellent cone crushing machine developed by introducing the cutting-edge technology from Germany. With a wide range of applications, the rock crusher equipment is specially designed for limestone, basalt and ore crushing. Additionally, this multiple cylinder hydraulic cone crusher is widely used in metal and non-metal mining, cement plant, sand and rock metallurgy industries, etc. As the latest generation of this popular rock crushing machine, it is well accepted as the optimal and ideal equipment for your varied selections.
Features
- Large crushing ratio and improved crushing efficiency;
- With stable performances, compact and perfect design of this multiple cylinder hydraulic cone crusher results in large production capacity and high production efficiency;
- The unique laminated crushing technique enables finished product size more uniform;
- The advanced hydraulic technology realizes the overload protection, which accordingly ensures steady and safe operation;
- Easy maintenance, easy to operate;
Technical data
| Model | YHP3™ | YHP4™ | YHP5™ | YHP6™ | YHP100™ | YHP200™ | YHP300™ | YHP400™ | YHP500™ | YHP800™ |
| Power (kW) | 250kW | 315kW | 370kW | 500kW | 90kW | 132kW | 200kW | 315kW | 355kW | 600kW |
| Crusher weight (kg) | 16100kg | 24200kg | 29000kg | 44550kg | 6740kg | 12160kg | 18100kg | 25600kg | 37000kg | 64100kg |
| Feed opening (mm) | ||||||||||
| Maximum | 220mm | 252mm | 317mm | 331mm | 150mm | 185mm | 241mm | 304mm | 351mm | 353mm |
| Capacity | ||||||||||
| CSS (mm) | Capacity（Mtph） | |||||||||
| 6mm | 45-55 | |||||||||
| 8mm | 94-122 | 135-175 | 158-205 | 50-60 | ||||||
| 10mm | 108-147 | 155-210 | 181-246 | 220-300 | 55-70 | 90-120 | 115-140 | 140-175 | 175-220 | 260-335 |
| 13mm | 138-185 | 195-265 | 229-311 | 280-380 | 60-80 | 120-150 | 150-185 | 185-230 | 230-290 | 325-425 |
| 16mm | 164-220 | 235-315 | 275-369 | 335-450 | 70-90 | 140-180 | 180-220 | 225-280 | 280-350 | 385-500 |
| 19mm | 182-241 | 260-345 | 304-403 | 370-490 | 75-95 | 150-190 | 200-240 | 255-320 | 320-400 | 435-545 |
| 22mm | 199-262 | 285-375 | 335-439 | 410-535 | 80-100 | 160-200 | 220-260 | 275-345 | 345-430 | 470-600 |
| 25mm | 210-279 | 300-400 | 352-460 | 430-570 | 85-110 | 170-220 | 230-280 | 295-370 | 365-455 | 495-730 |
| 32mm | 217-307 | 310-440 | 380-500 | 440-630 | 110-155 | 190-235 | 250-320 | 325-430 | 405-535 | 545-800 |
| 38mm | 251-349 | 360-500 | 422-550 | 515-715 | 210-250 | 300-380 | 360-490 | 445-605 | 600-950 | |
| 45mm | 279-388 | 400-555 | 468-600 | 570-790 | 350-440 | 410-560 | 510-770 | 690-1050 | ||
| 51mm | 465-630 | 580-790 | 785-1200 | |||||||
