GE2296 Raschel Machine

Double needle bar raschel knitting machine for producing shoe uppers, plush fabrics and spacer fabrics

Applications

Linings, short plush fabrics, shoe fabrics, three-layer spacer fabrics used in shoe uppers, clothing, and decorative items.

Features
  • Jacquard spacer fabric warp knitting machine uses an optimized cam connecting rod mechanism.
  • The spacer fabric warp knitting machine adopts a four-bar-linkage mechanism for knitting process.
  • The textile machinery utilizes short-stroke tongue needles for faster weaving speed and fabric output speed.
  • Jacquard spacer fabric warp knitting machine has functions of electronic yarn let-off, electronic fabric take-up, and independent batching.
Specifications
  • Needle type Individual latch needle, block latch needle
  • Gauge E18, E22, E24, E28
  • Number of bars 6/7/8 bars
  • Distance between knocking-over bar 2-16mm
  • Working width 90"/100"/110"/138"/170"/210"
  • Max. speed 800 rpm
  • Transmission method Optimized crankshaft connecting rod
Machine Model Dimensions (L×W×H) Floor Area (m²) Machine Weight (kg) Total Power (kW)
2296-90" 4100×5500×3400 22.55 8000 8.25
2296-100" 4450×5500×3400 24.475 9250 12.5
2296-110" 4800×5500×3400 26.4 10000 12.5
2296-138" 5500×5500×3400 30.25 12000 14.75
2296-170" 6100×5500×3400 33.55 14500 21
2296-210" 8300×5500×3400 45.65 17500 21.5
