GE2292 Raschel Machine (8 bars)

Double needle bar raschel knitting machine for producing jacquard plush fabrics

Applications

Regular jacquard plush fabrics

Features
  • High speed warp knitting machine uses an oil immersed cam-linkage mechanism and a fixed knock-over comb bar.
  • Raschel warp knitting machine adopts short latch needles for fast processing speed and fabric output.
  • Raschel warp knitting machine has functions of electronic yarn let-off, electronic fabric take-up and electronic guide bar control (EL).
Specifications
  • Needle type Block latch needle
  • Gauge E22
  • Number of bars 4 ground bars, 4 pile bars
  • Distance between knocking-over bar 2-16mm
  • Working width 100"/138"
  • Max. speed 550 rpm
Machine Model Dimensions (L×W×H) Floor Area (m²) Machine Weight (kg) Total Power (kW)
GE2292-100" 4800×6050×3400 29.04 10000 20.5
GE2292-138" 5500×6050×3400 33 12000 24
