GE2292 Raschel Machine

Double needle bar raschel knitting machine for producing plush fabrics and bedding fabrics

Applications

Short plush (milk velvet) fabrics, bedding fabrics, and sandwich fabrics.

Features
  • High speed warp knitting machine uses an oil immersed cam-linkage mechanism and a fixed knock-over comb bar.
  • The warp knitting machine adopts short latch needles for fast processing speed and fabric output.
  • Raschel warp knitting machine has functions of electronic yarn let-off, electronic fabric take-up and electronic guide bar control (EL).
Specifications
  • Needle type Block latch needle
  • Gauge E18, E22, E24, E26
  • Number of bars 4/5/6 bars
  • Distance between knocking-over bar 2-16mm
  • Working width 100"/110"/138"
  • Max. speed 850 rpm
Machine Model Dimensions (L×W×H) Floor Area (m²) Machine Weight (kg) Total Power (kW)
GE2292B-100" 4300×5600×3690 241 8500 9.5
GE2292B-110" 4800×5600×3690 26.9 10000 10.5
GE2292B-138" 5500×5600×3690 30.8 12000 12
