GE2266 Raschel Machine

Single needle bar knitting machine for producing elastic/non-elastic mesh and plain fabrics

Processing materials

Elastic or non-elastic mesh and plain fabrics

Applications

Swimwear, lingerie, stockings, tablecloths, curtains, decorative fabrics, apparel textiles, metal fabrics, etc.

Features
  • High speed raschel warp knitting machine adopts an optimized crankshaft connecting rod transmission mechanism.
  • Raschel warp knitting machine uses compound needles allows for knocking over from the bar, ensuring faster production speeds.
  • The single needle bar raschel warp knitting machine allows for electronic yarn let-off (EBA), electronic fabric take-up and electronic batching.
Specifications
  • Needle type Compound needle
  • Gauge E16, E28, E32
  • Number of bars 2/4 bars
  • Working width 170"
  • Max. speed 2300 rpm
Machine Model Dimensions (L×W×H) Floor Area (m²) Machine Weight (kg) Total Power (kW)
GE2266-170" 6500×2550×2950 16.95 10000 16.5
