High Speed Cord Knitting Machine
Request a Quote
Our high speed cord knitting machine can realize various complicated knitting processes used to create round cords. The machine is controlled by a frequency converter, enhancing its stability and resulting in high quality products that are more beautiful.
Parameters
| Model | Needle pipe | Needle | Braiding Dia range | Revolutio speed(rpm) | Motor |
| 04/08 | 3 | 4 | ø1-ø1.5 | 1000 | 1HP |
| 04/12 | 4.3 | ø1-ø3.5 | 1000 | 1HP | |
| 06/08 | 4 | 6 | ø1-ø1.5 | 800 | 1HP |
| 06/12 | 6 | ø4.5-ø6.5 | 800 | 1HP | |
| 08/06 | 4 | 8 | ø3.5-ø4.5 | 800 | 1HP |
| 08/06 | 6 | ø5-ø6.5 | 800 | 1HP | |
| 08/06 | 8 | ø6-ø8.5 | 800 | 1HP | |
| 08/06 | 10 | ø8-ø10.5 | 800 | 1HP | |
| 12/04 | 8 | 12 | ø7-ø8.5 | 500 | 1HP |
| 12/04 | 10 | ø7.5-ø10 | 500 | 1HP | |
| 12/04 | 14 | ø10-ø13.5 | 500 | 1HP | |
| Normal attachment | 128 Creel places,spare parts | ||||
