Reverberatory Furnaces

Reverberatory Furnaces
Request a Quote
Heating and Melting Equipment
Specifications
  • Type: molten bath
  • Shape: square
  • Energy: natural Gas
  • Structure: furnace casing, furnace lining, molten bath, electronic control system, combustion mechanism
Working Principle

The reverberatory furnace is utilized to melt non-ferrous metals like aluminum and zinc alloys. It is especially suitable for cooperative use with die casting machines for melting and holding secondary aluminum scrap.

Features
  • The material poured in the molten bath will not stick to the aluminum, which effectively controls the penetration of the molten metal into the material.
  • Natural gas burning heating source to achieve fast melting speed.
  • The furnace is directly heated by the flame to achieve high heat utilization and good heat preservation effect, and the gas consumption for melting one ton of aluminum is about 90m3.
  • The electronic control system automatically controls the operation of the burner according to the temperature inside the furnace to maximize energy efficiency.
  • The temperature control accuracy of molten aluminum can be up to ±5, which ensures the product quality and effectively reduces the defective index.
  • The crucible lasts many years, minimizing replacement costs.
Parameters
ModelMelting capacity (kg/h) Capacity (kg) Gas consumption (m3/h) Burner model Adaptive Die Cast Machine
HX-250 60-80 250 5-7.2 ON 125T below
HX-350 80-100 350 7.2-9 1N 125-350T
HX-500 100-200 500 9-18 2N 350-600T
HX-800 200-300 800 18-27 3N 600-1000T
HX-1200 300-500 1200 27-45 3N*2 1000-2000T
