GE2285-II Raschel Machine

Double needle bar raschel knitting machine for producing carpets, blankets and plush toys

Applications

Carpets, blankets and plush toys, apparel textiles

Features
  • Carpet warp knitting machine uses an oil immersed cam-linkage mechanism and fixed knock-over comb bars.
  • Raschel warp knitting machine has functions of electronic yarn let-off and electronic fabric take-up.
  • The textile machinery adopts special frame suitable for big beam (83×60 inch).
Specifications
  • Needle type Individual latch needle, block latch needle
  • Gauge E12, E14, E16, E18, E22
  • Number of bars 6 bars
  • Distance between knocking-over bar 8-30mm
  • Working width 180"
  • Max. speed 500 rpm
Machine Model Dimensions (L×W×H) Floor Area (m²) Machine Weight (kg) Total Power (kW)
GE2285- Ⅱ-180" 6600×8120×4300 53.46 15000 31
