GE259T

Warp knitting machine with parallel weft insertion for producing multi-axial carbon fiber fabric and fiberglass cloth

Applications

Suitable for processing high-performance fibers such as glass fiber, carbon fiber, and more. The produced multi-axial carbon fiber fabric and fiberglass cloth are widely used in aerospace, aviation, wind turbine blades, shipbuilding, construction, automotive, sports goods, and other fields.

Features
  • Production of multiaxial non-crimp fabrics with parallel weft insertion system in 0° and 90°.
  • The weft yarns can be fed-in online or offline.
Specifications
  • Needle type Compound needle
  • Gauge E5, E6, E7, E10, E12, E14
  • Number of guide bars 2 guide bar 1 ST
    1 guide bar 1 weft knitting bar
    2 guide bar 1 weft knitting bar
  • Working width 50"/101"
  • Weft laying system Adjustable between 20° and -20°
  • Max. speed 800 rpm
Machine Model Dimensions (L×W×H) Floor Area (m²) Machine Weight (kg) Total Power (kW)
GE259T-50" 30500×6200×3100 189.1 60000 36.6
GE259T-101" 30500×7500×3100 228.75 80000 42.7
