Overhead Lifting Bridge Crane with Electric Hoist

Request a Quote

View All: http://heavy-cranes.com/1-2-overhead-lifting-bridge-crane.html

Application:
The overhead lifting bridge crane with electric hoist is suitable for general lifting for loading and unloading operations in machinery manufacturing workshops, metallurgical plant auxiliary workshops, warehouses, stockpile, assembly stations, power station maintenance and other places. The suitable temperature range of its working environment is -25-40°C. It is not suitable for mediums with explosion risk or fire hazard. It is not suitable for installations with relative humidity greater than 85% or corrosive environments. It is also not suitable for lifting dissolved metals and toxic, flammable, or explosive items.

Parameters:

Gn=10t S=10.5～16.5

Rated lifting capacity

Span S(m)

10.5

13.5

16.5

Lifting speed

7/0.7

Trolley

Gauge S2(m)

1.4

Lifting Height

Working Speed (m/min)

Classification grade

Wheel Diameter D2(mm)

Φ270

Operation type

air operation or ground operation

Running motor

ZDY₁ 21-4 1.5KW×2

Elec-trichoist

Type

Single Speed HDD-5, Double Speed HDS-5

Cart

Basal spur W1(m)

3.2

3.4

Motor

Type

ZD₁41- or ADS₁41-4

Working Speed (m/min)

Power

131.5/13

Wheel Diameter D1(mm)

Φ270

Rotational Speed

m/min

1380

Length of gear boxes B1

3.6

3.8

Supporting power

3-phase 380V 50HZ

Operating Mechanism of bigcrane

Motor

type

Wire cable number

piece

Power(KW)

Wire rope diameter

Rotational Speed (r/min)

Winding drum

diameter

Φ342(about)

Reduction drive

type

LDA

length

800

980

Speed ratio(i)

pathway

For small crane

Kg/m

Max wheel-pressure

80.8

85.9

96.3

For big crane

38～42

Total Mass

8.4

9.24

11.4

10.5

13.5

16.5

1400

3600

3800

3200

3400

1650

370

727

Features:

This series of products have features compact dimensions, low building headroom, light weight, and low wheel pressure.
This electric double-girder bridge crane uses fixed-type wire rope electric hoist for its lifting structure (the main hook and the sub-hook). These cranes are mounted on a two-wheeled trolley that is matched with a double girder bridge. They can be divided into two kinds: double speed crane and single speed crane. It is typically used in single speed if the user has no special request, which means single speed is most common during ground operation.
There are 144 specifications in two varieties: cab control and ground control (handle control and wireless control). There are two kinds of operation rooms: open operation rooms and closed operation rooms, and according to the actual situation-installation types, they can be divided into two types: left side installation type and right side installation type. In addition, there are three kinds of enter direction: front side, end side, and top side, so we can meet the user's choice in a variety of different needs.
This electric double-girder bridge crane consists of four main components: bridge, cart, trolley and electric accessory.
Lifting capacity is divided into1t, 2t, 3t, 5t, 8t, 10t, 12.5t, 16t, 20t, 32t, totally 10 tonnages.
The crane operation, trolley running and hoisting mechanism are all related to limit switches, which can prevent these mechanisms on movement stroke. So in this way we can guarantee the operation safety.
