Automatic Two-Color Cylindrical Screen Printing Machine, JR-212UV

Request a Quote

View All: http://packaging-printer.com/1-2-screen-printing-machine.html

Screen printer for printing on round and cylindrical items

Optimized for dual-color printing on cylindrical items, the screen printing machine stands out. This type of screen printing equipment is typically used in environments that demand complex printing designs or multiple colors on items with diameters of 7 to 35 mm. Common applications include printing on toys, beverage bottles, and other cylindrical products.

Specifications

Printing Product Size (Diameter × Length): (7-35mm)×(30-120mm)
Maximum Printing Speed: 50pcs/min
Power Supply: 380V 3phase 50HZ
Compressed Air Pressure: 4-6bar
Power Consumption: 28kW
Machine Dimensions (L×W×H)
(excluding the size of discharging & drying line): 1600×1600×1900mm
Weight: 1600kg

Applications

Cosmetics industry Suitable for printing on items like eyeliners, lip gloss containers, mascara and lipstick tubes, providing vibrant and lasting colors.
Printing services Ideal for creating intricate designs on stationery and soft tubes, offering high-quality prints that stand out.
Medical auxiliary manufacturing Perfect for printing on medical syringes, ensuring clear and durable markings essential for medical safety.

Applicable inks

This screen printing press can be used with LED inks, UV inks, and thermosetting inks.

Features

This screen printer features a rotary design to achieve an efficient, continuous, and automated printing process.

Equipped with a servo motor drive for higher precision, performance, and flexibility in printing.

Includes both LED curing drying and hot air drying, making it compatible with LED, UV, and thermosetting inks.

The screen printer can be equipped with an optional CCD (Charge-Coupled Device) positioning for high-precision alignment during printing.

Accessories such as hot air guns, cameras, and curing oven units can be added upon demand.

Equipped with a system that prevents printing if an item is not correctly positioned or missing. The printing machine also has an advanced alarm system to avoid any loading or unloading issues.

Suitable for printing on a variety of round and tubular substrates, not limited to plastic and aluminum materials.

Before choosing a screen printing machine, it's important to confirm whether the screen printing quality meets your requirements. It’s also necessary to test the printing speed to ensure it aligns with your production goals. Lastly, consider the main components of the screen printer, the level of automation it offers, and how user-friendly it is.

If your projects require flexibility and you're working with a variety of products, a semi-automatic printing machine might be the right choice as they have a simpler structure and offers independent operation, suitable for general printing tasks. For larger-scale projects, where it’s necessary to print on high volumes of bottles quickly and consistently, a fully-automatic silk screen printing equipment is the best choice since is they’re designed to achieve high-speed mechanical transfers, is ideal for large-scale, mono color or multi-color printing production.

Our screen printing machines are versatile and widely used in many industries. For beauty packaging, they are perfect for printing on tubes and or containers of eyeliner, lip gloss, mascara, and lipstick. For food packaging companies, these screen printers can handle diverse packaging formats. Beverage filling companies also benefit from the precision and quality of our screen printers for their bottle labeling needs. In the medical industry, our printers play a crucial role in pharmaceutical packaging, especially for detailed printing on medical syringes. Additionally, packaging bottle manufacturers rely on our screen printing technology for its versatility and high-quality printing on various bottle types.
