2VM Series Cast Iron 2/2-Way Solenoid Valve

Request a Quote

Website: http://solenoidvalve-en.com/1-24-cast-iron-2-2-way-solenoid-valve-2vm-series.html

Direct Acting, Normally Closed
Port Size: 1/8"–1/4"
Fluid Temperature: -5°C to 80°C
Operating Pressure: 0–1.0MPa
Media: air, water, oil, gas

2VM series is a multifunctional modular solenoid valve featuring an aluminum housing with IP65 protection for a lightweight structure and environmental adaptability. Its modular structure allows a flexible combination of multiple valves through a shared air supply manifold, significantly simplifying pneumatic circuit layouts and reducing connection points and installation space.

Features

Compact structure with high flow capacity, fast response, and excellent sealing for low purity media
Low-power coil design, ideal for mobile and high-frequency applications
Standardized thread connections and modular units allow quick maintenance, replacement, or reconfiguration to reduce downtime
Shared manifold design reduces tubing length, minimizes leakage risk, and improves reliability

Applications

This solenoid valve is suitable for systems requiring space efficiency, frequent reconfiguration, or applications with high dustproof and waterproof requirements, such as:

Factory automation equipment
Packaging machinery
Industrial production lines
Multi-station pneumatic control systems

Dimensions (mm)

Specifications

Category	2/2-way solenoid valves
Mode of operation	Direct acting	Port size	1/8"–1/4"
Series	2VM	Function	Normally closed (NC)
Body material	Cast iron	Wiring	Flying leads / DIN connector
Control method	Solenoid valve	Protection level	IP65
Operating pressure	0-1.0MPa	Mounting	Modular assembly
Sealing material	NBR	Recommended installation method	Horizontally
Fluid temperature	-5℃ to 80 ℃	Thread options	BSP, NPT thread
