Portable Concrete Vibrator, Series ZRPNB
Request a Quote
ZRPNB series portable concrete vibrators features compact structure and light weight. Due to design of shoulder strap, the vibrator can be carried on shoulder easily during operation. The concrete vibrator is particularly suited for concrete vibration in hard-to-reach areas, where users can build their own houses (DIY) or implement small construction projects.
The vibrating poker head used in this portable concrete vibrator is an eccentric head, providing lower noise. The vibrator is powered by gasoline engine, meaning it suitable for working sites where the power grid is unavailable.
Optional Models
| Model | Vibrator head diameter (mm) | Vibrator head length (mm) | Vibrating frequency (Hz) | Vibrating frequency (vpm) | Amplitude (half value) (mm) | Amplitude (total value) (mm) | Overall dimension L×W×H (mm) | Total weight (kg) |
| ZRPNB29 | 29 | 344 | 165 | 9900 | 0.6 | 1.2 | 2770×300 ×400 | 10.1 |
| ZRPNB39 | 39 | 334 | 150 | 9000 | 0.85 | 1.7 | 2760×300 ×400 | 10.9 |
| ZRPNB45 | 45 | 366 | 150 | 9000 | 1.25 | 2.5 | 2792×300 ×400 | 11.5 |
Components of Portable Concrete Vibrator
Vibrator Head
- The eccentric shaft structure of this vibrating poker head ensures that the vibrator can start its vibration without slipping.
- The head cap and outer casing are all made of high quality carbon steel and treated by heat treating process to ensure its service life.
Gasoline Engine
Model: GX35 (other models can be customized)
Fuel: Unleaded Gasoline
Power: 0.95kW
Speed: 10000rpm
Fuel: Unleaded Gasoline
Power: 0.95kW
Speed: 10000rpm
Flexible Hose & Flexible Shaft
Outer diameter of hose: 32mm
Inner diameter of hose: 18mm
Flexible shaft diameter: 12mm
Total length: 2m
Inner diameter of hose: 18mm
Flexible shaft diameter: 12mm
Total length: 2m
