MPO Fiber Optic Cable, Single Mode and Multimode
Request a Quote
Applications
Specifications- CATV, and Multimedia
- Telecommunication networks
- Active device interface
- Telecommunication networks
- Gigabit Ethernet
- Data processing networks
- Interconnection for O/E modules
- Premise installations
- Optical switch interframe connection
- Asynchronous Transmission Mode (ATM)
| Item | Single mode | Multimode | ||
| Standard | Low loss | Standard | Low loss | |
| Insertion Loss | <=0.75dBtypical<=0.5dB | <=0.35dBtypical<=0.2dB | ≤0.5dBtypical<=0.35dB | ≤0.35dBtypical<=0.2dB |
| Return Loss | ≥60 dB (APC | ≥30 dB (PC) | ||
| Repeatability | ≤0.1dB | |||
| Durability | ≤0.2 dB typical change, 500 matings | |||
| Interchangeability | ≤0.2dB | |||
| Tensile strength | >70N | |||
| Operating Temperature | -40 to 85°C | |||
