Single Person Suspended Platform
Request a Quote
Main Descriptions of Single Person Suspended Platform
It is a kind of Suspended Access Equipment, also known as Temporary Access Equipment, widely used for cleaning and maintenance work on the confined areas, such as high buildings, large-size tank, ship, and bridge, etc.
Key features of Single Person Suspended Platform
–single hoisting machine, using centrifugal safety lock
–proper structure, easy to operate, and safety securely guaranteed
–fast to assemble and disassemble, less cost to rigging work
–easy to store
Technical Data of ZLP250 Single Person Suspended Platform
| Model | ZLP250 |
| Rated capacity (kg) | 250 |
| Lift speed (m/min) | 9.6 |
| Platform dimension(m) | 1.2*0.7*1.17 |
| Wire rope diameter | 8.3mm |
| Working height | 100m |
| Motor power (Kw) | 1.5 |
| Voltage | 380V 50Hz |
| Brake torque (Nm) | 15 |
| Safety lock type | LSL30 Centrifugal type |
| Suspended mechanism projecting length (m) | 1.3~1.5m |
| Adjustable height of the beam | 1.44~2.14m |
| Weight of suspension mechanism | 150kg |
| Counter weight | 400kg |
