H-XZB-ES350 C-Frame Transfer Mould Press
Applications
CHAP C-Frame Transfer type molding machine is suitable for producing difficult-to-mold rubber products, like those with metal insert, complex shape, big cross section and thick wall.
| H-XZB-ES350 | |
| Clamping force | 350 KN |
| Clamping stroke | 300 mm |
| Rapid clamping speed | ≥30 mm/s |
| Heating plate size | 300mm×350mm |
| Heating plate spacing | 30~330 mm |
| Max operating temperature of heating plate | 250 ℃ |
| Material cylinder spec | ￠40mm×165mm |
| Injection stroke | 270 mm |
| Injection pressure | 80 Mpa |
| Motor power | 3 KW |
| Heating power | 4.4 KW |
| External dimension (LxWxH) | 1000mm×1500mm×2345mm |
| Oil tank capacity | 200 L |
CHAP is a major manufacturer and supplier of C-Frame Transfer type molding machine in China. Our company is located in Ningbo City which provides us with convenient transportation. Therefore, we can deliver our vacuum rubber vulcanizing machine, plate rubber vulcanizing machine, custom rubber machine, etc. to you in time. These products are manufactured in conformity with the standard of ISO, so our worldwide customers can feel secure in inquiring and ordering. In addition, we establish long term cooperative relationship with material suppliers, which helps reduce our material purchasing cost. Therefore, we can provide rubber machinery at reasonable prices. If you have any need, please contact us directly. We look forward to cooperating with you. Thank you.
