Introduction

The multilayer screen separator can remove small impurities such as straw and leaves from unprocessed grains such as wheat, rice, corn and beans.

The multilayer screen separator includes a TQLM150*2 multilayer screen separator with two-layer sieves and a TQLM150*4 multilayer screen separator with four-layer sieves. The more sieves there are, the better the cleaning effect is. So compared with the TQLM150*2 separator, the TQLM150*4 is more suitable for eliminating small and light impurities.

Parameter

Type	Capacity	Power	Air intake volume	Weight	Dimensions (LWH)
TQLM150*2 (two sieves)	40-45T/H	2.2 0.75Kw	8000-9000M³/H	4500Kg	336726602555mm
TQLM150*4 (four sieves)	80-90T/H	3 0.75Kw	10000-11000M³/H	6000Kg	345226603398mm

Features

With suspension structure, the multi-layer screen system of the multilayer screen separator works rotationally, which can reduce the damage of screen system which won't impact other parts when moving and makes sure the grain is distributed more evenly.
The multilayer screen separator with automatic feeding device has stable and evenly distributed feeding, which is beneficial for eliminating and separating impurities.
The aspirators are installed in the feed inet and grain outlet. Light impurities will leave grains with the wind when grain falls, which make the separator has better cleaning effect.
The combined screen system contains sieve meshs made from metal and sieves. Sieves are even perforated metal plates which are high strength, small footprint, durability and simple change. Customers can choose sieves with different perforations according to the size and content of impurities in order to achieve better separating effect.
The multilayer screen separator has an automatic sieve cleaning device, and can collect impurities automatically, which gives the machine better separating effects and prevents perforations from being blocked by impurities. Besides, the device solves the problem of manual sieve cleaning and reduces operating costs.
The multilayer screen device equipped with vibration detector and motor drive with brake can stop fast and can reduce vibration to a certain degree.
The multilayer screen separator has air adjustment device which can adjust air volume according to impurity content to ensure the cleaning effect.

Effect comparison

First Time
Second Time
Last Time
