Vertical Form Fill Seal Machine DXDT-300

Vertical Form Fill Seal Machine DXDT-300
Vertical Form Fill Seal Machine DXDT-300
Vertical Form Fill Seal Machine DXDT-300
Vertical Form Fill Seal Machine DXDT-300
Vertical Form Fill Seal Machine DXDT-300
Vertical Form Fill Seal Machine DXDT-300
Vertical Form Fill Seal Machine DXDT-300
Request a Quote

(0.5-200g)

Packing Sample Pictures

Technical Parameters
Model DXDT-300 automatic packaging machine with chain bucket
Sealing type 3/4 side sealing, back sealing or triangle bag
Method of measurement Chain bucket
Range of measurement 0-350ml
Packaging speed 20-40 bags/min 30-50 bags/min 40-60 bags/min
Bag size W: 30-150mm L: 30-170mm
Power 1600W
Voltage 380V, 220V or customized
Machine weight 260 kg
Dimensions 950×1280×1700mm


Features
1. In this vertical form fill seal machine, the part directly contacting with materials is made from SUS304 stainless steel, in order to guarantee high hygiene.

2. The packaging equipment provides variable-frequency speed adjustment and passes CE certificate. It automatically completes bag making, measuring, filling, sealing, cutting and counting by itself.

3. A micro-computer LCD is installed for intelligent control.

4. The malfunction alarm system and electric control cabinet both contribute to 24-hour continuous running of the packaging machine.

5. With the use of a stepping motor, the automatic packaging system is capable to pack materials at a customized length or flexible length. There is no need to adjust the parameter, saving time and film. Plus, the vertical form fill seal machine will automatically give an alarm while film shortage.

6. The temperature is controlled by an intelligent solid-state double-loop PID controller for suiting various types of packaging materials. A protection device is also equipped to ensure packaging material and product will not be burned.

7. Optional configurations include ribbon printer, filling device, gas-exhaust device and beating device.

8. The drive system possesses compact structure, reliable performance and convenient maintenance.

9. Applicable materials are PET/PE, Paper/PE, PET/AL/PE and OPP/PE.
