Automatic Vertical Flanging Machine
Request a Quote
The ST-B14VY automatic vertical flanging machine is suitable for the flanging of round 3-piece cans with diameter of 202-401D. It is widely used in different scale can production factories.
Features- Vertical design. It only covers a small area and its products can be seamlessly and smoothly transported to the next process.
- Weight of 2800 kg to ensure a smooth operation
- Max. Capacity: 400 cpm
- Central lubricating (underside)+manual lubricate(upside)
| Machine type | ST-B14VY | |
| Flanging head | 4H | 6H |
| Range of can dia. | 202D-401D | |
| Range of can height | 50-160 mm | |
| Capacity per minute | Up to 300 cpm | Up to 400 cpm |
| Horse power required | 2.2 + 0.75 + 0.18 KW | |
| Floor space &overall height | 1700×1000×2465 mm | |
| Net weight | 2500 kgs | 2800 kgs |
| Height of input station | 850 mm | |
| Lubricate | Central lubricating system(underside)&manual lubricate(upside) | |
| Speed control | Inverter | |
